ASUS ROG STRIX RTX 4060 GAMING
RTX 40 · ROG STRIX RTX 4060 GAMING · RTX 4060
General
| Series | RTX 40 |
|---|---|
| Model | ROG STRIX RTX 4060 GAMING |
| Chip | RTX 4060 |
| Launch Year | 2023 |
| Release Date | 5/18/2023 |
| Launch MSRP | $299 |
Is this part compatible with your build?Analyze part compatibility together with PC Analysis.
Analyze in PC Builder
Analyze in PC Builder
Architecture
| Architecture | Ada Lovelace |
|---|---|
| GPU Die | AD107 (AD107-400-A1) |
| Foundry | TSMC · 5 nm |
| Transistors | 18.9 billion |
| Die Size | 159 mm² |
Cores
| Shading Units | 3072 |
|---|---|
| TMUs | 96 |
| ROPs | 48 |
| SM / CU | 24 |
| Tensor Cores | 96 |
| RT Cores | 24 |
| L2 Cache | 24 MB |
Memory
| VRAM | 8 GB |
|---|---|
| Memory Type | GDDR6 |
| Memory Bus | 128-bit |
| Memory Speed | 17 Gbps |
Clocks and Power
| Base Clock | 1830 MHz |
|---|---|
| Boost Clock | 2460 MHz |
| TDP | 115 W |
| Power Connector | 8-pin |
Compute (TFLOPS)
| FP32 | 15.36 TFLOPS |
|---|---|
| FP16 | 15.36 TFLOPS |
| FP64 | 0.24 TFLOPS |
Display Outputs
| HDMI | 1× |
|---|---|
| DisplayPort | 3× |
Cooling
| Fan Count | 3 |
|---|---|
| Liquid Cooling | ✗ No |
Physical
| Length | 311 mm |
|---|---|
| Width | 62 mm |
| Height | 134 mm |
| Slot Width | 3.1 slot |
Interface
| PCIe Version | 4.0 |
|---|---|
| PCIe Lanes | x8 |
Software and Technologies
| API Support | DirectX 12 Ultimate (12_2) CUDA 8.9 Vulkan 1.3 OpenCL 3.0 OpenGL 4.6 Shader Model 6.7 |
|---|---|
| Hardware Encoder | 1x NVENC (8th Gen, max 8 sessions) 1x NVDEC (5th Gen) |
| Encoding | AV1 (YUV 4:2:0) H.265 (4K YUV 4:2:0/4:4:4, 4K Lossless, 8K, HEVC 10bit, HEVC B Frame) H.264 (YUV 4:2:0/4:4:4, Lossless) |
| Decoding | AV1 (8bit/10bit) H.265 (8/10/12bit 4:2:0, 8/10/12bit 4:4:4) H.264 (8bit 4:2:0) VP9 (8/10/12bit) VP8 VC-1 MPEG-2 MPEG-1 |
