Gigabyte Gaming 750GM PG5

750 W · 80 PLUS Gold · ATX 3.1
Gigabyte Gaming 750GM PG5 product image
Gigabyte Gaming 750GM PG5 product image 1Gigabyte Gaming 750GM PG5 product image 2Gigabyte Gaming 750GM PG5 product image 3Gigabyte Gaming 750GM PG5 product image 4

Specifications

Wattage750 W
80 PLUS Certification80 PLUS Gold
ATX StandardATX 3.1
Cable designFully modular
Form FactorATX PS/2
Warranty10 years
Graphics card connector1× 12V-2x6 (native)
Is this part compatible with your build?Analyze part compatibility together with PC Analysis.
Analyze in PC Builder

Features

PFC✓ Yes (Active)

Design

Width150 mm
Depth150 mm
Height86 mm
ColorBlack

Cables and Connectors

IDE / Molex4×
SATA8×
Floppy1×
PCIe 6+2-pin4×
CPU 4+4-pin (ATX12V)2×
Motherboard 24-pin1×

Efficiency

· manufacturer90%

Fan

Fan size135 mm
Operating modeSemi-passive (stops at low load)
