SilverStone SFX Series SX750-PT Platinum

750 W · 80 PLUS Platinum · SFX
SilverStone SFX Series SX750-PT Platinum product image
SilverStone SFX Series SX750-PT Platinum product image 1SilverStone SFX Series SX750-PT Platinum product image 2SilverStone SFX Series SX750-PT Platinum product image 3

Specifications

Wattage750 W
80 PLUS Certification80 PLUS Platinum
ATX StandardSFX
Cable designFully modular
Form FactorSFX
ColorBlack
Dimensions (W×D×H)125 × 100 × 64 mm
Weight1.01 kg
PFCActive
Warranty5 years
FeaturesErP Lot 6
Is this part compatible with your build?Analyze part compatibility together with PC Analysis.
Analyze in PC Builder

Cables and Connectors

IDE / Molex3×
SATA8×
EPS12V 8-pin1×
PCIe 6+2-pin4×
CPU 4+4-pin (ATX12V)2×
Motherboard 24-pin1×

Efficiency

· manufacturer92%
115V · 80plus_official91%
115V · cybenetics90.01%
230V · cybenetics91.35%

Noise

115V · cybenetics38.49 dB(A)
230V · cybenetics39.09 dB(A)

Fan

Fan size92 mm
Operating modeSemi-passive (stops at low load)
